Asus P8H77-M LE User Manual

ix
P8H77-M LE specications summary
ASUS unique features ASUS DIGI+ VRM
ASUS EPU
ASUS MemOK!
GPU Boost
ASUS AI Suite II
ASUS Anti-Surge Protection
ASUS UEFI BIOS featuring graphics user interface
ASUS CrashFree BIOS 3
ASUS EZ Flash 2
ASUS MyLogo 2™
ASUS Q-Fan 2
100% All High-quality Conductive Polymer Capacitors
Rear panel ports 1 x PS/2 keyboard / mouse combo port
1 x HDMI port
1 x DVI-D port
1 x D-Sub port
1 x LAN (RJ-45) port
4 x USB 2.0 ports
2 x USB 3.0 ports (blue)
3 x Audio jacks
Internal connectors/
switches/ buttons
1 x USB 3.0 connector supports additional 2 USB 3.0 ports
3 x USB 2.0 connectors support additional 6 USB 2.0 ports
4 x SATA 3.0 Gb/s connectors (blue)
2 x SATA 6.0 Gb/s connectors (gray)
1 x CPU fan connector
1 x Chassis fan connector
1 x Chassis intrusion connector
1 x Front panel audio connector (AAFP)
1 x S/PDIF output connector
1 x System panel connector
1 x Speaker connector
1 x 24-pin ATX power connector
1 x 8-pin EATX 12V power connector
1 x MemOK! button
1 x Clear CMOS jumper
BIOS features 64 Mb Flash ROM, UEFI BIOS, PnP, DMI v2.0, WfM 2.0,
ACPI v2.0a, SM BIOS v2.5, Multi-language BIOS, ASUS
CrashFree BIOS 3, ASUS EZ Flash 2
Manageability
WOL, PXE, PME Wake Up
Accessories 2 x Serial ATA 6.0Gb/s cables
1 x I/O shield
1 x User Manual
1 x Support DVD
Support DVD Drivers
ASUS utilities
ASUS Update
Anti-virus software (OEM version)
Form factor
MicroATX form factor: 9.6 in x 8.2 in (24.4 cm x 20.8 cm)
* Specications are subject to change without notice.

Asus P8H77-M LE Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600, 1800, 1866, 2000, 2133, 2200 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
USB 2.0 connectors	3
Number of SATA II connectors	4
Number of Parallel ATA connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Audio chip	Realtek ALC887
Cooling type	Passive
Component for	PC
Power source type	ATX
Motherboard chipset	Intel H77
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Supported storage drive interfaces	SATA II, SATA III
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1696 MB
Parallel processing technology support	LucidLogix Virtu
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x16
Cables included	SATA
LAN controller	Realtek RTL8111F
Wi-Fi standards	Not supported
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	AMI
ACPI version	2.0a
BIOS memory size	64 Mbit

Weight and Dimensions

Depth	208 mm
Width	244 mm
