2-48 Chapter 2: Hardware information
Chapter 2
2.3.11 Rear panel connection
Rear panel connectors
1. Intel
®
LAN (RJ-45) port** 6. USB 3.0 ports 1 and 2
2. Power eSATA 6G port 7. Optical S/PDIF Out port
3. Bluetooth module* 8. USB 3.0 ports 3 and 4
4. USB 2.0 ports 1,2,3 and 4 9. USB 2.0 ports 5 and 6
5. BIOS Flashback switch 10. Audio I/O ports***
*, ** and ***: Refer to the tables on the next page for bluetooth module LED, LAN port LED, and
audio port denitions.
