Asus Prime H310M-C User Manual

ASUS PRIME H310M-C
1-1
Product introduction
1
Motherboard overview
• Unplugthepowercordfromthewallsocketbeforetouchinganycomponent.
• Beforehandlingcomponents,useagroundedwriststraportouchasafelygrounded
objectorametalobject,suchasthepowersupplycase,toavoiddamagingthemdue
tostaticelectricity.
• Beforeyouinstallorremoveanycomponent,ensurethattheATXpowersupplyis
switchedofforthepowercordisdetachedfromthepowersupply.Failuretodoso
maycauseseveredamagetothemotherboard,peripherals,orcomponents.
• Unplugthepowercordbeforeinstallingorremovingthemotherboard.Failuretodoso
cancauseyouphysicalinjuryanddamagetomotherboardcomponents.
Place this
side towards
the rear of the
chassis
ScantheQRcodetogetthedetailedpindenitions.
M.2(SOCKET3)
PCIE SATA IRST
X2 V X
PCIEX16
PCIEX1_1
PCIEX1_2
PCI
ASM
1083
ASM1480
LPT
TPM
LPC DEBUG
SPEAKER
CLRTC
F_PANEL
CHASSIS
U31G1_12
AAFP
EATXPWR
CPU_FAN
CHA_FAN
BATTERY
Super
I/O
ALC
887
DIGI
+VRM
24.4cm(9.6in)
DDR4 DIMM_B1* (64bit, 288-pin module)
LGA1151
2280 2260
M.2(SOCKET3)
DDR4 DIMM_A1* (64bit,288-pin module)
AUDIO
KBMS
LAN_U31G1_34
USB5-8
19.3cm(7.6in)
128Mb
BIOS
SATA6G_2
SATA6G_1
SATA6G_3SATA6G_4
DVI
COM1
VGA
Intel
®
H310
ATX12V
COM2
USB914
1 52 43
1
8 1011
1
1
6
1
8
1
9
1
7
18
1213141516
17
19
20

Asus Prime H310M-C Specifications

General

Microphone in	Yes
USB 2.0 ports quantity	4
Ethernet LAN (RJ-45) ports	1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity	0
ECC	No
Memory channels	Dual-channel
Memory slots type	DIMM
Supported memory types	DDR4-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
Audio chip	Realtek ALC887
Component for	PC
Power source type	ATX
Motherboard chipset	Intel® H310
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Motherboard chipset family	Intel
Windows operating systems supported	Windows 10
Maximum resolution	1920 x 1200 pixels
Processor socket	LGA 1151 (Socket H4)
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Pentium
Intel® Core i3/i5/i7/i9 series	i3-8xxx, i5-8xxx, i7-8xxx
Supported storage drive interfaces	M.2, SATA III
BIOS type	UEFI AMI
ACPI version	6.1
BIOS memory size	16 Mbit
System Management BIOS (SMBIOS) version	3.1
LAN controller	Realtek RTL8111H
Ethernet interface type	Gigabit Ethernet
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	193 mm
Width	244 mm
