Asus Q170T Manual

1-4
Chapter 1: Product introduction
M.2 socket 3
ThissocketallowsyoutoinstallanM.2(NGFF)SSDmodule.Usethebundled
screw13020-0181000tosecureyourM.2device.
ThissocketsupportsMKeyand2242/2260/2280storagedevices.
Clear RTC RAM (2-pin CLRTC)
ThisheaderallowsyoutocleartheCMOSRTCRAMdataof
thesystemsetupinformationsuchasdate,time,andsystem
passwords.
To erase the RTC RAM:
1. TurnOFFthecomputerandunplugthepowercord.
2. Useametalobjectsuchasascrewdrivertoshortthetwo
pins.
3. PlugthepowercordandturnONthecomputer.
4. Holddownthe<Del>keyduringthebootprocessand
enterBIOSsetuptore-enterdata.
CLRTC
+3V_BAT GND
PIN 1
Ifthestepsabovedonothelp,removetheonboardbatteryandshortthetwopinsagain
tocleartheCMOSRTCRAMdata.AfterclearingtheCMOS,reinstallthebattery.
Intel
®
ME jumper (3-pin DIS_ME)
ThisjumperallowsyoutoenableordisabletheIntel
®
MEfunction.Setthisjumper
topins1-2toenable(default)theIntel
®
MEfunctionandtopins2-3todisableit.
DisabletheIntel
®
MEfunctionbeforeupdatingit.
Front panel audio connector (10-1 pin AAFP)
Thisconnectorisforachassis-mountedfrontpanelaudioI/Omodulethatsupports
HDAudio.ConnectoneendofthefrontpanelaudioI/Omodulecabletothis
connector.
Werecommendthatyouconnectahigh-denitionfrontpanelaudiomoduletothis
connectortoavailofthemotherboard’shigh-denitionaudiocapability
DMIC connector (5-1 pin DMIC)
TheDMICconnectorisforconnectingthedigitalmicrophonemoduleusedinAll-
in-Onechassis.
24
Internal stereo speaker header (4-pin SPK_OUT)
Theinternalmonospeakerheaderallowsconnectiontoaninternal,low-power
speakerforbasicsystemsoundcapability.Thesubsystemiscapableofdrivinga
speakerloadof4Ohmsat3Watts(rms).
E11582_Q170T_UM.indb 4 2016-05-05 10:16:51
