78
Notebook PC E-Manual
Removing the compartment cover
A. Pull the rubber cover to expose the screw underneath.
IMPORTANT! The rubber cover is designed to be attached to the
Notebook PC’s compartment cover. DO NOT force to detach it or
completely remove it from the compartment cover.
B. Remove the screws from the Notebook PC’s compartment cover.
C. Pull out the compartment cover and remove it completely from
your Notebook PC.
To Next Page
