1-24
Chapter 1: Product Introduction
Chapter 1
15. AURA RGB LED connector
TheAURARGBLEDconnectorallowsyoutoconnectRGBLEDstrips.
TheAURARGBLEDconnectorsupports5050RGBmulti‑colorLEDstrips(12V/G/R/B),
withamaximumpowerratingof3A(12V).
Beforeyouinstallorremoveanycomponent,ensurethatthepowersupplyisswitchedoff
orthepowercordisdetachedfromthepowersupply.Failuretodosomaycausesevere
damagetothemotherboard,peripherals,orcomponents.
• ActuallightingandcolorwillvarywithLEDstrip.
• IfyourLEDstripdoesnotlightup,checkiftheRGBLEDextensioncableandthe
RGBLEDstripisconnectedinthecorrectorientation,andthe12Vconnectoris
aligned with the 12V header on the motherboard.
• TheLEDstripwillonlylightupwhenthesystemispoweredon.
• TheLEDstripispurchasedseparately.
