ROG STRIX TRX40-E GAMING
2-9
Chapter 2
2.1.7 Front I/O connector
To install USB 3.2 Gen 2 connectorTo install ASUS Q-Connector
This connector will only t in one
orientation. Push the connector until it
clicks into place.
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
To install system speaker connector
USB 3.2 Gen 2
