2-2
ASUS LCD Monitor PG Series
2.3 Detaching the arm/stand (for VESA wall
mount)
• Avoid damaging the monitor surface. While detaching the
monitor stand, always keep the monitor inside its EPS
packaging.
The detachable stand of this monitor is specially designed for VESA wall
mount.
To detach the arm/stand
1. Disconnect power and signal cables. Carefully put the monitor
facedown on its EPS packaging.
2. Remove the covers on where the monitor and the arm meet.
3. Remove the four (4) screws securing the arm to the rear of the
monitor.
4. Detach the stand (arm and base) from the monitor.
1
1
2
2
• Use only the UL Listed Wall Mount Bracket with minimum
weight/load 28.8 kg (Screw size: M4 x 10 mm).
