Asus TUF GAMING A520M-PLUS User Manual

ASUS TUF GAMING A520M-PLUS
2-5
2.5 RAIDcongurations
The motherboard comes with the RaidXpert2 Conguration Utility that supports RAID 0,
RAID 1 and RAID 10 conguration.
RAIDdenitions
RAID 0 (Data striping) optimizes two identical hard disk drives to read and write data in
parallel, interleaved stacks. Two hard disks perform the same work as a single drive but at a
sustained data transfer rate, double that of a single disk alone, thus improving data access
and storage. Use of two new identical hard disk drives is required for this setup.
RAID 1 (Data mirroring) copies and maintains an identical image of data from one drive to
a second drive. If one drive fails, the disk array management software directs all applications
to the surviving drive as it contains a complete copy of the data in the other drive. This RAID
conguration provides data protection and increases fault tolerance to the entire system. Use
two new drives or use an existing drive and a new drive for this setup. The new drive must be
of the same size or larger than the existing drive.
RAID 10 is data striping and data mirroring combined without parity (redundancy data) having
to be calculated and written. With the RAID 10 conguration you get all the benets of both
RAID 0 and RAID 1 congurations. Use four new hard disk drives or use an existing drive
and three new drives for this setup.
For more information on conguring your RAID sets, please
refer to the RAIDCongurationGuide which you can nd at
https://www.asus.com/support, or by scanning the QR code.

Asus TUF GAMING A520M-PLUS Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 3rd Gen, AMD Ryzen 9 3rd Gen
Component for	-
Motherboard chipset	AMD A520
Audio output channels	- channels
Motherboard form factor	micro ATX
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200, 3333, 3466, 3600, 3733, 3866, 4000, 4133, 4266, 4400, 4466, 4600, 4800 MHz
Supported storage drive interfaces	M.2, SATA
USB 3.2 Gen 1 (3.1 Gen 1) connectors	2
PS/2 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Firewire (IEEE 1394) ports	0
Wi-Fi	No
Ethernet LAN	Yes
BIOS type	UEFI AMI
BIOS memory size	256 Mbit
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	244 mm
