Asus TUF GAMING X570-PRO WI-FI User Manual

2-12
Chapter 2: Basic Installation
Chapter 2
2.1.8 Front I/O connector
USB 3.2 Gen 2
To install USB 3.2 Gen 2 connector
This connector will only fit in one
orientation. Push the connector
until it clicks into place.
USB 2.0
AAFP
To install USB 2.0 connector
To install front panel audio connector
USB 3.2 Gen 1
To install USB 3.2 Gen 1 connector
To install the front panel connector

Asus TUF GAMING X570-PRO WI-FI Specifications

General

Chipset	AMD X570
CPU Socket	AM4
Form Factor	ATX
Memory Slots	4 x DIMM
Maximum Memory	128 GB
Memory Type	DDR4
SATA Ports	8 x SATA 6Gb/s
RAID Support	RAID 0, 1, 10
PCIe Slots	2 x PCIe 4.0 x16
M.2 Slots	2 x M.2
Bluetooth	Bluetooth 5.1
USB Ports	4 x USB 2.0
Audio	Realtek ALC S1200A 7.1 Surround Sound High Definition Audio Codec
