2-1
Chapter 2: Setup
2.1
Detaching the arm/stand (for VESA wall
mount)
The detachable stand of this monitor is specially designed for VESA wall
mount.
1. Disconnect power and signal cables. Carefully put the front of the
monitor face down on a clean table.
2. Loosen the screw located at the bottom of the base. Then remove the
base from the stand.
3. Or you may directly use a screwdriver to remove the screws that
secure the stand to the monitor, and detach the stand from the
monitor.
• We recommend that you cover the table surface with soft cloth to prevent
damage to the monitor.
• Hold the base while removing the screw.
1
2
3
• The VESA wall mount kit ( 100 x 100 mm) is purchased separately.
• Use only the UL Listed Wall Mount Bracket with minimum weight/load
22.7kg (Screw size: M4 x 10 mm).
To Next Page
