Asus VIVOMINI VC66 SERIES - Initial Setup and Connections

14
VivoMini VC66 Series
Getting started
Connect the AC power adapter to your VivoMini
To connect the AC power adapter to your VivoMini:
A. Connect the power cord to the AC power adapter.
B. Plug the AC power adapter into a 100V~240V power source.
C. Connect the DC power connector into your VivoMini’s power
(DC) input.
IMPORTANT!
• WestronglyrecommendthatyouuseonlytheACpowercord
that came with your VivoMini.
• Westronglyrecommendthatyouuseagroundedwallsocket
while using your VivoMini.
• Thesocketoutletmustbeeasilyaccessibleandnearyour
VivoMini.
• TodisconnectyourVivoMinifromitsmainpowersupply,unplug
your VivoMini from the power socket.
• Poweradapterinformation:
- Input voltage: 100-240Vac
- Input frequency: 50-60Hz
- Rating output current: 6.32A max. (120W) / 9.23A max. (180W)
- Rating output voltage: 19V / 19.5V
