Asus X99-E WS User Manual

3-60
Chapter 3: BIOS setup
Chapter 3
3.9 Tool menu
The Tool menu items allow you to congure options for special functions. Select an item then
press <Enter> to display the submenu.
GPU Post
This item shows the installed graphics cards in your motherboard. It also shows the
recommended number of graphics card to install to your motherboard for best performance.
Setup Animator
This item allows you to enable or disable the Setup animator.
Conguration options: [Disabled] [Enabled]
3.9.1 ASUS EZ Flash 2 Utility
This item allows you to run ASUS EZ Flash 2. When you press <Enter>, a conrmation
message appears. Use the left/right arrow key to select between [Yes] or [No], then press
<Enter> to conrm your choice.
For more details, refer to section 3.11.2 ASUS EZ Flash 2.

Asus X99-E WS Specifications

General

Headphone outputs	1
eSATA ports quantity	2
IPMI LAN (RJ-45) port	Yes
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	10
Number of SATA III connectors	8
Memory channels	Quad-channel
Supported memory types	DDR4-SDRAM
Maximum internal memory	128 GB
Supported memory clock speeds	2133, 2400, 2666, 2800, 3000, 3200 MHz
BIOS type	UEFI AMI
ACPI version	5.0
BIOS memory size	128 Mbit
Wi-Fi	No
LAN controller	Intel® I210-AT
Ethernet interface type	Gigabit Ethernet
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	10 - 35 °C
Operating relative humidity (H-H)	20 - 90 %
Lithography	22 nm
Processor socket	LGA 2011-v3
Intel Xeon series	E5-1600, E5-2600
Processor manufacturer	Intel
Parallel processing technology support	4-Way CrossFireX, 4-Way SLI
Component for	Server
Motherboard chipset	Intel® X99
Motherboard form factor	SSI CEB
PCI Express x16 (Gen 1.x) slots	7
Supported storage drive interfaces	SATA

Weight and Dimensions

Depth	267 mm
Width	305 mm
