xiv

Installation tools and components

The tools and components in the table above are not included in the motherboard package.

PC chassis

Power supply unit

Intel

LGA2011-v3 compatible CPU Fan

Intel

LGA2011-v3 CPU

DIMM

SATA hard disk drive

Graphics card

Philips (cross) screwdriver

SATA optical disc drive (optional)

1 bag of screws
