2-28 Chapter 2: Hardware information
2.8 Audio card installation
1. Take out the Audio card from the
package.
2. Locate the PCI Express x1 MIO
slot on the motherboard.
3. Align the card connector with the
slot and press rmly until the card
sits on the slot completely.
4. The photo below shows the
audio card installed on the
motherboard.
