ASUS Z87-EXPERT

1-1

Chapter 1

Product introduction

1.1 Special features

1.1.1 Product highlights

LGA1150 socket for 4th generation Intel

Core™ i7/Intel

Core™ i5/Intel

Core™ i3, Pentium

and Celeron

processors

This motherboard supports 4th generation Intel

Core™ i7/Intel

Core™ i5/Intel

Core™

i3,

Pentium

, and Celeron

processors in the LGA1150 package. It provides great graphics and

system performance with its GPU, dual-channel DDR3 memory slots and PCI Express 2.0/3.0

expansion slots.

Intel

Z87 Express Chipset

Intel

Z87 Express Chipset is a single chipset that supports the LGA1150 socket for 4th

generation Intel

Core™ i7/Intel

Core™ i5/Intel

Core™ i3, Pentium

and Celeron

processors. It utilizes the serial point-to-point links, which increases bandwidth and enhances

the system’s performance. It natively supports up to six USB 3.0 ports for up to ten times

faster transfer rate than USB 2.0 and enables the iGPU function for Intel

integrated graphics

performance.

PCI Express

3.0

PCI Express

3.0 (PCIe 3.0) is the PCI Express bus standard that provides twice the

performance and speed of PCIe 2.0. It provides an optimal graphics performance,

unprecedented data speed and seamless transition with its complete backward compatibility

to PCIe 1.0/2.0 devices.

Dual-Channel DDR3 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) / 2500 (O.C.) / 2400

(O.C.) / 2200 (O.C.) / 2133 (OC.) / 2000 (O.C.) / 1866 (O.C.) / 1800 (O.C.) / 1600 // 1800 (O.C.) / 1600 / / 1600 /

1333 MHz Support

The motherboard supports the dual-channel DDR3 memory that features data transfer rates

of DDR3 2800 (O.C.) / 2666 (O.C.) / 2600 (O.C.) / 2500 (O.C.) / 2400 (O.C.) / 2200 (O.C.) /

2133 (OC.)  2000 (O.C.)  1866 (O.C.)  1800 (O.C.)  1600  1333 MHz to boost the system’s1800 (O.C.)  1600  1333 MHz to boost the system’s1600  1333 MHz to boost the system’s

performance, and to meet the higher bandwidth requirements of 3D graphics, multimedia and

Internet applications.

Quad-GPU SLI and CrossFireX™ Support

This motherboard features the most powerful Intel

Z87 platform that optimizes PCIe

allocation in multi-GPU SLI and CrossFireX™ solution, giving you a brand-new gaming

enjoyment.

Chapter 1: Product Introduction

Questions and Answers:

Need help?

Do you have a question about the Asus Z87-EXPERT and is the answer not in the manual?

Asus Z87-EXPERT Specifications

General

ECC	No
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR3-SDRAM
Maximum internal memory	32 GB
Supported memory clock speeds	1333, 1500, 1600, 1666, 1800, 1866, 1900, 2000, 2100, 2133, 2200, 2250, 2400, 2450, 2600, 2666, 2800, 3000 MHz
Processor socket	LGA 1150 (Socket H3)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Pentium
Maximum number of SMP processors	1
Number of SATA III connectors	8
Number of Parallel ATA connectors	0
HDMI version	1.4a
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	6
Audio chip	Realtek ALC1150
Cooling type	Passive
Component for	PC
Motherboard chipset	Intel® Z87
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	ATX
RAID levels	0, 1, 5, 10
Supported storage drive interfaces	SATA, SATA II, SATA III
Graphics card	HD Graphics
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	2-Way CrossFireX, 2-Way SLI, 3-Way CrossFireX, Quad-GPU CrossFireX, Quad-GPU SLI
PCI Express x16 slots	3
PCI Express slots version	2.0, 3.0
PCI Express configurations	1x4, 1x16, 2x8
Cables included	SATA
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	4.0
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
BIOS memory size	64 Mbit
