Asus ZenWiFi AX Mini User Manual

Relocation
FAQ
Locate the AiMesh router and node at the best place.
NOTES: To minimize interference, keep the routers away from devices like cordless phones, Bluetooth
devices and microwave ovens.
We recommend that you place the routers in an open or spacious location.
Solid white: Good signal
Solid yellow: Weak signal
Solid red: No signal
ZenWiFi AX Mini LED indications
Q1:
Does the AiMesh router support Access Point mode?
A: Yes. You can choose to set the AiMesh router as router mode or access
point mode. Please go to web GUI (http://router.asus.com), and go to the page
Administration > Operation Mode.
