EN 16
INSTALLATION
- Before installing the cooker hood fit the
electric unit upright (Fig.4).
- Secure the bracket with the four screws G,
as indicated in Figure 5.
Fig.4 Fig.5
- Place the bracket against the wall, align it with the two highest holes. Secure it with two
supplied screws. For assembly, screws and expansion plugs should be used that are suitable
for the wall type (for example reinforced concrete, plasterboard, etc.). If screws and plugs are
supplied with the hood, make sure in advance that these are suitable for the wall on which the
hood is to be installed.
Fig.3
