EN 11
INSTALLATION
Connection
Electrical connection
This is an (insulation) class II (double insulated) device. This means
that the cable does not have to be connected to an earthed socket.
Check that the Voltage state don the type plate corresponds with the
Voltage on the home installation.
Connection to the Electricity grid must be as follows:
BROWN = L phase
BLUE = N neutral
This extractor fan is fitted with a connection plug. Install the extractor
fan in such way that the plug is accessible. Place the wall socket
preferably out of sight, behind the decorative tube.
Attention: If you make a permanent connection you must ensure that an
omnipolar switch with a contact gap of a minimum of 3 mm is fitted in
the supply cable.
