EN 10
INSTALLATION
Electrical connection
This appliance is manufactured in class I, it must therefore be
connected to the earth system.
Make sure the supply voltage ratings correspond with those stated on
the appliance data plate. The connection to the mains is carried out as
follows:
BROWN = phase L
BLUE = phase N
YELLOW/GREEN = Earth
During the electrical connection make sure that the electrical socket is
equipped with earth connection.
This built in unit has been provided with a power plug. When installing
the hood, make sure that this plug remains accessible.
Attention:
If you want to make a fixed connection, ensure that a multi-pole switch
with a distance between contacts of 3 mm is installed in the supply
cable.
max. 100 mm
