AT&T IPC-1600 - Page 6

Table of Contents
Appendices
A.
Hardware Parameter Settings
Switch, Jumper, Connector Location Information
DS1 Switch Settings—Controller Memory Starting
Address
DS1 Switch Settings—I/O Port Address
DS2 Switch Settings—Interrupt Request Level
Local Program Memory Size Select Jumper J1
Sample Configuration Record
B. Serial Input/Output Device Interface
Serial Port Characteristics
Voltage Envelope
IPC-1600 80-Pin Headers P3 and P4
16-Ports Fanout Module Assembly
RJ-45 Type Modular Jack Connector
Data Terminal Equipment (DTE) Connections
Data Circuit-Terminating Equipment (DCE)
Connections
10-Conductor Modular Cables
A-1
A-3
A-8
A-10
A-12
A-13
B-1
B-2
B-3
B-7
B-9
B-10
B-16
B-19
iv IPC-1600 USER’S GUIDE
