IPC-1600 Diagnostics
You are next asked to select the starting memory address for the board to
be tested as follows.
Select the appropriate number (1-7) for the IPC-1600 memory address:
1)80000H 2)90000H
3)A0000H 4)B0000H
5)C0000H 6)D0000H
You are then asked to specify the IRQ level for the board to be tested as
follows.
7)E0000H
Select the appropriate number (1-8) for the IPC-1600 IRQ:
1)3 2)4 3)5
4)7 5)10 6)11 7)12
8)15
After the I/O address, starting controller memory address, and IRQ level
are entered, any of the six tests can be repeated/executed by entering the test
number. A record is maintained on the screen of the number of times each
test is executed, the number of times each test passed, and the number of
times each test failed. The following screen shows the initial conditions after
the board to be tested has been defined.
------------------------------------------------------------------------------
********
IPC-1600 DIAGNOSTICS
***********
Version 1.5.0
********
-------------------------------------------------------------------------------
ESC will exit the IPC-1600 diagnostics and return to the system.
IPC-1600 Selected parameters:
I/O = 100
Memory
= 80000H
IRQ = 10
Select the appropriate test number (1-6):
TOTAL
PASS FAIL
1) Host 64K dual-ported memory tests
00
00 00
2) Host/IPC-1600 interface tests
00 00
00
3) IPC-1600 64K dual-ported memory tests
00 00
00
4) IPC-1600 16K local memory tests
00 00
00
5) IPC-1600 FEPOS integrity tests
00 00 00
6) IPC-1600 Communication ports tests
00 00
00
*******************************************************************************
7-6 lPC-1600 USER’S GUIDE
