ATC entry Series User Manual

30°
30°
distance x
distance y
distance z
distance x = distance y = distance z
Loudspeaker Positioning - Stereo
Acoustic Axis
acoustic axis:
mid-point between bass/mid and tweeter
2-way systems
acoustic axis:
mid-range driver
3-way systems
Fig. 1
Fig. 2
ENTRY MANUAL 040919_ENTRY BROCHURE 13.3 10/09/2019 15:19 Page 7
