ATC SCM11 User Manual

3:Specifications : Stereo/Satellite Models
Drivers : HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm CLD Matched Response : +/- 0.5dB Frequency Response (-6dB) : 56Hz–22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Sensitivity : 85dB @ 1W @ 1metre Max SPL : 108dB
Recommended Power Amplifier : 75 to 300 Watts Nominal Impedance : 8 Ohm Crossover Frequency : 2.2kHz
Connectors : Binding Posts/4mm Plugs, bi-wire Cabinet Dimensions (HxWxD) : 380x232x235mm (grill adds 28mm to depth) Weight : 10.9kg
Drivers : HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 125mm SC Matched Response : +/- 0.5dB Frequency Response (-6dB) : 60Hz–22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Sensitivity : 84dB @ 1W @ 1metre Max SPL : 103dB
Recommended Power Amplifier : 75 to 300 Watts Nominal Impedance : 8 Ohm Crossover Frequency : 2.5kHz
Connectors : Binding Posts/4mm Plugs, bi-wire Cabinet Dimensions (HxWxD) : 300x173x215 (grill adds 28mm to depth) Weight : 7.5kg
Drivers : HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm Super Linear Matched Response : +/- 0.5dB Frequency Response (-6dB) : 54Hz–22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Sensitivity : 85dB @ 1W @ 1metre Max SPL : 108dB
Recommended Power Amplifier : 75 to 300 Watts Nominal Impedance : 8 Ohm Crossover Frequency : 2.5kHz
Connectors : Binding Posts/4mm Plugs, bi-wire Cabinet Dimensions (HxWxD) : 438x265x300mm (grill adds 34mm to depth) Weight : 17.8kg
Drivers : HF ATC 25mm dual suspension Tweeter, Mid ATC 75mm Soft Dome, LF ATC 165mm SC Matched Response : +/- 0.5dB Frequency Response (-6dB) : 48Hz-22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Sensitivity : 85dB @ 1W @ 1metre Max SPL : 112dB
Recommended Power Amplifier : 75 to 300 Watts Nominal Impedance : 8 Ohm Crossover Frequencies : 380Hz & 3.5kHz Connectors : Binding Posts/4mm Plugs, tri-wire
Cabinet Dimensions (HxWxD) : 980x370x305mm (inc. foot plinth, spikes add 25mm to height, grill adds 34mm to depth) Weight : 31kg
SCM7
SCM40
SCM19
SCM11
Drivers : HF ATC 25mm dual suspension Tweeter, Mid 75mm ATC Soft Dome, LF ATC 164mm SC Matched Response : +/- 0.5dB Frequency Response (-6dB) : 48Hz–22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Max SPL : 112dB Crossover Frequencies : 380Hz & 3.5kHz Connectors : Male XLR
Input sensitivity : 1V Filters : 4th Order critically damped with phase compensation Overload Protection : Active FET momentary gain reduction
Fault Protection : DC fault protection and thermal trip. Fault indication on rear panel mounted LED Amplifier Output : 150W LF, 60W MF, 32W HF
Cabinet Dimensions (HxWxD) : 980 x 370 x 344mm (inc. foot plinth and amplifier stand-offs. Spikes add 25mm to height, grill adds 34mm to depth) Weight : 36kg
SCM40A
Drivers : HF ATC 25mm dual suspension Tweeter, Mid/LF ATC 150mm SL Matched Response : +/- 0.5dB Frequency Response (-6dB) : 54Hz-22kHz
Dispersion : ±80° Coherent Horizontal, ±10° Coherent Vertical Max SPL : 108dB Crossover Frequency : 2.5kHz Connectors : Male XLR
Input sensitivity : 1V Filters : 2nd Order critically damped with phase compensation Overload Protection : Active FET momentary gain reduction
Amplifier Output : 150W LF, 32W HF
Cabinet Dimensions (HxWxD) : 980x370x344mm (inc. foot plinth & amp, spikes add 25mm to height, grill adds 34mm to depth) Weight : 31kg
SCM19A
ENTRY MANUAL 040919_ENTRY BROCHURE 13.3 10/09/2019 15:19 Page 22
