Replacement Parts List for Models Atd-7430 Series A & Atd-7431 Series A:
7
Item Description Qty.
28 U-Cup, Ram 2
29 O-Ring 1
30 O-Ring 3
31 O-Ring 1
32 Back-up Washer 1
33 O-Ring 1
34 O-Ring 1
35 Filter 1
36 O-Ring 1
37 Back-up Washer 1
38 Back-up Washer 1
39 O-Ring 1
40 O-Ring 1
41 Back-up Washer 1
42 Seal 1
43 Seal 1
44 Back-up Washer 1
45 Back-up Washer 1
46 O-Ring 1
47 O-Ring 1
48 O-Ring 1
49 Back-up Washer 1
G3601S-111
(Atd-7430 Series A)
G3600S-130
(Atd-7431 Series A)
Repair Kit for Hydraulic
Unit (includes parts
28 - 49)
Item Part No. Description Qty.
1 G360-20000-000 Leg Assembly 2
2 G360-90030-K04 Bolt Set (4 sets) 1
3 G360-90030-K02 Caster, 3" Dia. 2
4 G360-90030-K01 Caster w/ Brake 2
5 5105-08015-000 Socket Head Bolt 1
6 4200-03500-000 Tilt Screw Assy. 2
7 G360-40000-000 Saddle Head Assembly 1
8 A070-90038-K02 Screw Assembly 2
9 G360-90009-K01 Vent Screw Assembly 1
10 G390-20000-000 Handle Assembly 1
11 G251-00007-000 Handle Grip 2
12 5104-10040-000 Bolt 1
13 5206-00010-000 Nylon Nut 1
14 G390-10005-000
Release Valve Pedal
(2pc. for Atd-7431 Series A)
1
15 5405-07027-000
Pin
(2pc. for Atd-7431
Series A)
1
16 5405-02018-000
Retaining Pin
(2pc. for Atd-7431 Series A)
1
17 G390-30000-000 Lift Pedal 1
18 5405-12070-000 Axle 1
19 5405-02028-000 Retaining Pin 1
20 G831-00002-000
Coupler, Male 1/4NPT
(Atd-7431 Series A only)
1
21 G360-10003-000
Air Hose
(Atd-7431 Series A only)
1
22 G360-10002-000
Spring
(Atd-7431 Series A only)
1
23 G360-16000-000
Hose Connector, Elbow
(Atd-7431 Series A only)
2
24 G360-17000-000
Air Motor
(Atd-7431 Series A only)
1
25 5308-00120-000
Copper Washer
(Atd-7431 Series A only)
1
26 G390-41000-000 Nylon Strap Assy 1
27 5102-10016-000 Bolt 1
Repair Kit Contents:
