Atec AV32OPD - DTV Mode Specification; Chassis and Function General Specification

800 * 600 35.156 56.25 36.0 VESA
800 * 600 37.879 60.317 40.0 VESA
800 * 600 48.077 72.188 50.0 VESA
800 * 600 46.875 75.0 49.5 VESA
832 * 624 49.726 74.551 57.284 MAC
1024 * 768 48.780 60.001 64.11 MAC
1024 * 768 48.363 60.004 65.0 VESA
1024 * 768 56.476 70.069 75.0 VESA
1024 * 768 60.241 74.927 81.724 MAC
1024 * 768 60.030 75.029 78.75 VESA
1152 * 864 67.500 75.0 104.993 VESA
1152 * 870 68.681 75.062 100.0 MAC
1280 * 768 47.700 60.0 80.136
1360 * 768 47.700 60.0 80.136
◆ DTV Mode Spec
Resolution
H
Frequency(KHz)
V
Frequency(Hz)
Pixel
Frequency(MHz)
Comment
720 * 480 15.735 59.94 13.500 SDTV,DVD 480i
720 * 576 15.735 50.0 13.595 SDTV,DVD 576i
720 * 480 31.469 59.94 25.175 SDTV, 480p
720 * 576 31.250 50.0 26.566 SDTV, 576p
1280 * 720 44.964 59.94 74.176 HDTV, 720p
1280 * 720 37.500 50.0 60.466 HDTV, 720p
1920 * 1080 33.750 60.0 74.25 HDTV, 1080i
1920 * 1080 28.125 50.0 70.723 HDTV, 1080i
◆ SHASSIS / FUNTION General Spec.
NO ITEM DESCRIPTION REMARK
1 MODEL NAME VCB4430
Marker LG Philips LCD 2 TARGET PANEL
Type LCD LC260W02 LC320W02
Type D-SUB 15p *1, HDMI * 1 3 RGB/HDMI
Frequency H:31∼80KHz, V:56∼75Hz
