Type RCA Jack (Green, Blue, Red)*1
480i: 59.94/60Hz, 480p: 59.94/60Hz
765i:50Hz, 765p: 50Hz
4 COMPONENT
Mode
720p: 59.94/60Hz, 1080i: 50/59.94/60Hz
SD and HD
CVBS: RCA Jack(yellow)*1, VCB4430
Half SCART *1 VCB4430
Type
SVHS: Mini-Din 4P *1. Auto Select
5 VIDEO INPUT
System PAL, SECAM
6 AV OUTPUT Selected TV, Video and Audio Out through SCART EU
7 AUDIO INPUT 3.5Ф Phone Jack*2 for PC
8 AUDIO OUTPUT Connector for Internal *1
9 TUNER Din Connector * 1 (inter Bridge for sub tuner)
LOCAL MENU, SELECT(SOURCE), DOWN, UP, LEFT, RIGHT, POWER, LED 10 CONT
ROL
REMOTE Infrared- Rays NEC Format
Dynamic/Standard/Mild/Game/;User PSM
User Brightness, Contrast, Color, Sharpness
CSM CSM/ Brightness/ Contrast
CSM Normal/Warm/User
User Red/Green/Blue
Effect Flat/Music/Movie/Speech/User
User Bass, Treble
Surround On/Off, Normal, Spatial
AVL On/Off
AUDIO
Balance L(-10)----0---- R(10)
PIP,
POP
Source, Swap, PIP size,
PIP position
PIP/POP/P
BP
On/Off ON
PBP Source, Swap
Language English/ Deutsch/Francois/Italiano/ Espanol EU
Language China, English HK
Transparency 50(1 ∼ 100)
Auto/16:9/14:9/4:3 AV/TV Aspect
4:3/16:9 PC
Factory Reset On/Off
11 OSD
GUI
Setup
Time Clock/Off Time/On Time/Audio off
PIP/PBP Mode Supporting
SUB
MAIN
TV AV1 AV2 COMPONENT RGB HDMI
TV ⅹ ⅹ ⅹ ○ ○ ○
AV1 ⅹ ⅹ ○ ○ ○
AV2 ⅹ ⅹ ○ ○ ○
COMPONEN ○ ○ ○ ⅹ ⅹ
