Atex ECO 6 - Technical Features; ECO 6 Controller Specifications

ECO 6 – User and installation manual
Release 5.1 5
ECO 6 CONTROLLER
Power Supply
230Vac – 50/60Hz
Dimensions
L156 x W87 x H38mm
Logic
Microcontroller
Inputs
N°3 NTC [-49.9, +99.9]°C
N°2 door switch and high pressure switch
Relay outputs
30A-5A-5A-5A-5A-5A
Gates
Nr 2 CANBUS
Sensors
Power Supply
Board Temperature
OREDER CODES:
BT92204100 [WITHOUT HOUSING]
BT92204000 [WITH 9 DIN MODULE HOUSING]
