SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
5.2 PRECAUTIONS
6 SL1: FRONT VIEW
Observe the following rules to proceed with the installation of the SL1 Data Logger on the vehicle:
Work in a comfortable environment (example: sufficient work space)
Disconnect the battery
Put all the parts removed from the vehicle in a safe place, making sure not to damage them
Install the system when the engine is cold: during installation, it could come into contact with
hot parts
Carefully handle the connectors and wiring (avoid contact with sharp or hot surfaces)
Keep the washers, nuts and bolts in a safe place during system installation
Install the system so that it does not interfere with moving parts or with the pilot
ATTENTION: INCORRECT INSTALLATION COULD CAUSE PERSONAL
INJURY OR PROPERTY DAMAGE
5: MAIN connector
6: EXP connector
7: USB connector
4: GPS antenna connector
3: DIAGNOSTICS LED - Red
2: GPS LED - Yellow
1: STATUS LED - Green
