8 SL1:OPERATING DIAGRAM
First use
Normal use
INSTALLATION
LynXLog & WinTAX4
WinTAX4 JUNIOR
ACTIVATION
ARCHIVE FOLDER
SETTING
(Base Directory)
INSTALLATION OF SL1
DATA LOGGER
IN THE VEHICLE
CONNECT
SL1 DATA LOGGER TO
PC
CONFIGURE THE
ACQUISITION
PARAMETERS
CHANNELS,
TRIGGERS, INFO ETC.
CONNECT SL1 DATA
LOGGER TO THE PC
CONFIGURE THE
ACQUISITION
PARAMETERS
IF NECESSARY
DATA LOGGING DATA DOWNLOAD
WITH
LYNXLOG
DATA ANALYSIS
WITH
WINTAX
