9 BEHAVIOUR OF THE LEDs
The SL1 Data Logger LEDs provide information concerning system status.
See the following tables:
AVVIAMENTO
LED TYPE STATUS DESCRIPTION
Green GPS Flashing System control
Yellow SYSTEM ON System control
Red DIAGNOSTICS ON System control
NORMAL CONDITIONS
LED TYPE STATUS DESCRIPTION
Green GPS OFF GPS signal OK
Green GPS Flashing GPS signal search
Yellow SYSTEM ON System ready
Yellow SYSTEM Flashing Acquisition in progress
Red DIAGNOSTICS OFF System OK
Red DIAGNOSTICS Flashing System in alarm
SHUT-OFF
LED TYPE STATUS DESCRIPTION
Green GPS OFF GPS signal OK
Yellow SYSTEM Flashing Acquisition in progress
Red DIAGNOSTICS OFF System OK
SYSTEM UPDATE OTA FUNCTION AND ACQUISITION CONFIGURATION
LED TYPE STATUS DESCRIPTION
Green GPS ON GPS signal OK
Yellow SYSTEM ON Acquisition in progress
Red DIAGNOSTICS Flashing System OK
DROM 5s TO 10s
FROM 20s TO 30s
FROM 3s TO 6s
OTA Update
