SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
12.5.2 OPEN THE SETUP FILE .SET
The setup files saved on the PC can be loaded or modified or sent to the SL1 Data Logger with the
following procedure:
• Run LynXLog
• Open the acquisition configuration page by pressing the Log Config button or pressing the
icon on the navigation bar
• Press the Open Conf. button to open the import window
• Select the setup file to open and press open
• Once the setup is open its components will be listed in the Config Channel Tree column, press
an element to open its panel.
