12.5.1 DOWNLOADING THE SETUP FROM SL1
The setup saved in the SL1 Data Logger can be downloaded as follows:
• Connect the SL1 Data Logger to the PC (see chapter 12.1)
• Open the setup configuration page by pressing the Log Config button or pressing the icon
on the navigation bar
• Press the button > Read Conf. to import the setup from the SL1 Data Logger:
• Once the setup was imported, its components will be listed in the Config Channel Tree, press
an element to open its panel
