SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
13 SL1 DATA LOGGER TECHNICAL SPECIFICATIONS
Electrical specifications:
Main power supply input (Main): 9-18 VDC
Optional power supply input: 5 VDC (mini USB port)
Auxiliary power supply output (example: sensor power supply): 5VDC - 70mA max.
System specifications:
Internal backup battery: Rechargeable 3.7VDC LiOn battery
Internal memory: 7 GB Flash
System clock: Integrated Real Time Clock (RTC) and GPS clock
Integrated GPS specifications:
Sensitivity: 167dB - update frequency :10Hz (up to
18Hz) with active external antenna
Integrated sensors:
9 axis inertial system with Sensor Fusion
technology (3D accel. and 3D gyro)
GPS status LED:
✓
Status LED:
✓
Acquisition status LED:
✓
GPS antenna connector: SMA
Type of casing: high resistance plastic
Mechanical dimensions:
21mm x 62mm x 79mm (without cables and
antenna connector)
Weight: 167g
IP degree: IP 67
Firmware update:
✓ (via WiFi or via USB)
Wiring specifications:
Main SL1 cable:
9-pin HRS connector (DF62W-9EP-2.2C) – cable
length: 150mm
SL1 expansion cable:
8-pin JST connector (08T-JWPF-VSLE-D) – cable
length: 150mm
SL1 USB cable: Sealed Mini USB connector – cable length: 500mm
Standard input specifications:
Analogue signal input: 3 analogue inputs (signal range 0-5V)
Frequency input:
1 frequency input (frequency range 0-20kHz) for
RPM or WHEEL speed
Bus data characteristics:
CAN port:
2 2.0 High Speed ports (125 – 250- 500 kb/s,
1Mb/s) Intel/Motorola format
Serial port: 1 communication port RS232
Connectivity:
USB 2.0 port:
✓
BLE:
✓
WiFi :
✓ (model GK-SL1-0001 only)
Software:
Desktop software
SL1 Data Logger Tool and WinTAX4 analysis
software
