SL1 DATA LOGGER User Manual Rev. AD
sales.get@athena.euwww.getdata.it
ENGLISH
1 SET INFO
The INFO panel can be opened by pressing INFO&DEF.PATH in the Config Channel Tree column:
The following information can be set here:
• Setup Author: name of the setup author
• Event: name of the event (competition etc..)
• Weather: weather conditions
• Note: additional notes for the acquisition
• Run comment: comment for the Run
• Track name: sets the track name (changes the storage path)
• Session: assigns a name to the session (changes the storage path)
• Driver: sets the name of the pilot
• Vehicle: sets the name of the vehicle (changes the storage path)
The changes can be made by pressing the relative text.
Make the necessary configurations and save the setup or send it to the SL1 Data Logger when
finished.
For the archive path: Track name, Session and Vehicle will influence the path of the data stora-
ge folder as follows:
Base directory \ Track \ Session \ Vehicle Name \ Run_name\....file downloaded
Where:
• Base directory: this is the main folder for the storage path - set on the DATA path (see chap.
12.2).
• Track: this is the first subfolder of the storage path – its value is set by the Track name on the
setup INFO panel.
• Session: this is the second subfolder of the storage path – its value is set by the Session on
the setup INFO panel.
• Vehicle Name: this is the third subfolder of the storage path – its value is set by the Vehicle
on the setup INFO panel.
• Run_name: this is the last subfolder of the storage path – its value is set by “Run_“ followed
by the progressive number of the session created by the SL1 Data Logger.
