GasSens Gas Detection System Section 2 - A14 Receiver Module
O & M Manual
A14-RK, 8/06 2 - 14
RECEIVER MODULE PARTS LIST
PLUG-ON TERMINAL BLOCK (38-0009)
FRONT PANEL (34-0009)
PLUG-ON TERMINAL BLOCK (38-0006)
TOP HALF OF ENCLOSURE (80-0002)
PC BOARD ASSEMLBY
BOTTOM HALF OF ENCLOSURE (80-0002)
Part Number Description
00-0056 Complete receiver module (Specify Gas)
80-0002 Module enclosure (top and bottom)
34-0009 Front panel
38-0009 Relay terminal block plug, 12 position
38-0006 DC terminal block plug, 12 position
