GasSens Gas Detection System Section 4 - Optional Equipment
O & M Manual
A14-RK, 8/06 4 - 3
BATTERY BACKUP PARTS LIST
Part Number Description
00-0057 Complete battery back-up unit
01-0011 Battery back-up circuit board
80-0009 NEMA 4X enclosure (top and bottom)
48-0010 Battery bracket
29-0002 Battery, 12 V, 4 A-H
92-0022 Self-tapping screws, (Pkg. Of 2)
44-0017 Pg 16 to 1/2" NPT conduit hub
44-0018 Pg 16 Seal Ring (required for NEMA-4X rating on hub)
STROBE PARTS LIST
Part Number Description
35-0002 Red Strobe, 12-80 VDC
35-0005 Red Strobe, 120 VAC
35-0004 Amber Strobe, 12-48 VDC
35-0006 Amber Strobe, 120 VAC
