While the AMC provides VGA Feature Connector (VFC) compatibility, it
also provides enhanced features for new multimedia devices including
serial control and provision for audio.
The AMC connector shares the same footprint with the VFC but it adds
pins for supporting additional multimedia modes. Great caution should
be taken when connecting a ribbon cable to the AMC/VFC connector.
Some of the pins carry power and any improper use can result in damage
both to the graphics card and the upgrade board.
