4 RADEON™ 8500/ RADEON 7500™ User’s Guide
DISPLAY CABLE
TO VGA MONITOR
TO DIGITAL/ANALOG DEVICE WITH DVI CONNECTOR
DVI-I-TO-VGA
ADAPTER
DVI-I
CONNECTOR
VGA
CONNECTOR
ON CARD
FROM
MONITOR
TO TV/VCR
