Atlanta EVA - RESTART AFTER AN ALARM OR AS RESULT OF TORN; FINISHED FILM

Atlanta Stretch S.p.A.
23
E08
Carriage ascend/descend
anomaly
- The sensor does not read the
petals because it is too far from the
phonic wheel.
- The carriage only moves in one
direction.
- The sensor does not send the
signal to the card.
- The roll holder carriage does not
move, even with manual controls.
- Adjust the position of the sensor compared to
the petals of the phonic wheel (distance < 2
mm). If the phonic wheel is broken or damaged,
it must be replaced.
- Check if the control signal reaches the drive,
then verify if the status LED is lit. Check if the
carriage limit switch is pressed or blocked.
-
Check the correct operation of the sensor,
bringing it close to a metallic object. If the LED
lights up, replace the cable, if the sensor does
not work, it needs to be replaced.
- The drive or inverter does not receive consent
to start, check the wiring. The drive or inverter
is faulty, communicate the code shown on
the latter. For a DC motor, check the brushes.
The motor cable is not connected well, check
the wiring and tightness, even on the brake, if
present. The motor unit may be damaged or
defective; replace it. Check the battery.
E09
-
-
broken.
-
-
to the product.
- Change the roll.
-
- Check the proper operation of the dancer sensor
does not work, make sure the sensor is operating
-
(x) seconds, the alarm is triggered. Attache
E10
Carriage limit switch
error
- Wiring or power outage error - Check the limit switch wiring and power Check
the carriage motor brushes.
E11
Low limit switch error:
it did not close during
carriage ascent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
- Unblock the sensor or replace it if faulty. Check
the carriage motor brushes.
E12
High limit switch error:
it did not close during
carriage descent
- Carriage motor blockage
- Limit switch faulty or blocked.
- Check the carriage motor (motor brushes).
- Unblock the sensor or replace it if faulty.
E13
Low limit switch error: it
opened during carriage
ascent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
E14
High limit switch error: it
opened during carriage
descent
- The carriage moves in the opposite
direction.
- Invert the rotation direction or the limit switches
are inverted.
