Operator Panel | TURNTABLE - MAST
24
E16
Emergency intervention - Emergency button pressed.
- Carriage door open.
-
Unblock the button and restore the power
circuit.
- Close the door and restore the power circuit.
If FE or FM carriage, check the bridge on the
connector. Check the emergency microswitch.
E20
Non-volatile memory
error functions (I2C) #0
- No response from memory. - Replace the memory I
2
C (24LC256).
E21
Non-volatile memory
error functions (I2C) #1
- Memory timeout. - Replace the memory (24LC256).
E22
Non-volatile memory
error functions (I2C) #2
- Communication error. - Replace the memory (24LC256).
E23
Non-volatile memory
error functions (I2C) #3
- Communication error. - Replace the memory (24LC256).
E24
Non-volatile memory
error functions (I2C) #4
- Memory occupied. - Replace the memory (24LC256).
E25
Non-volatile memory
error functions (I2C) #5
- Write error. - Replace the memory (24LC256).
E26
Non-volatile memory
error hidden parameters
(EE) #1
- Periphery occupied. - Replace the microcontroller (PIC).
E27
Non-volatile memory
error hidden parameters
(EE) #2
- Interruption during writing. - Replace the microcontroller (PIC).
E28
Non-volatile memory
error hidden parameters
(EE) #3
- Failed check given after writing. - Replace the microcontroller (PIC).
E29
Non-volatile memory
error hidden parameters
(EE) #4
- Timeout writing data. - Replace the microcontroller (PIC).
E50
Error in creasing position
sensors
- Both sensors are engaged. -
Check the proper electrical wiring or proper
installation and mechanical operation.
E51
Creasing locked during
closure
- Creasing blocked on the top sensor. - Check motor operation.
- Check electrical connection
- Make sure there are no mechanical obstacles.
- Check sensor operation
E52
Creasing block during
opening
- Creasing blocked on the bottom
sensor.
- Check motor operation.
- Check electrical connection
- Make sure there are no mechanical obstacles.
- Check sensor operation
E53
Top limit switch error: did
not engage during ascent
command (creasing)
- The carriage blocked during ascent. - Check motor operation.
- Check operation of the top sensor and replace
if broken.
- Make sure there are no mechanical obstacles.
