Atlantic 180 - PACKING, TRANSPORTATION AND STORAGE; A1. Packing; A2. Transportation; A3. Storage

ATLANTIC 180/200
19/30
SPARE PARTS LIST FOR MAINTENANCE
No.
Material Code
Name of Material
1
10007251
IGBT-FGH40N60
2
10007253
IGBT-FGH60N60
3
10037794
IGBT- GD60SGK60T2S
4
10006272
Rectifying tube WSAD92-02
5
10006248
Rectifying tube D92-02
6
10006271
Rectifying tube FFA60UP30DE
7
10005801
Electrolytic capacitor CD-470uF-400V
8
10037138
Electrolytic capacitor CD-560uF-400V
9
10005848
Electrolytic capacitor CD-680uF-400V
10
10033189
Integrated circuit UC3846ON)
11
10006677
Integrated circuit TL084
12
10006282
NMOS tube IRFZ24N
13
10006284
PMOS tube IRF9Z24N
14
10037146
TOP266KG(ESOP-12)
15
10037147
LM79L15ACMX(SO-8)
PACKING, TRANSPORTATION AND STORAGE
A1. Packing
No.
Name
Unit
Quantity
1
User’s manual for ARC series (English)
Volume
1
2
Product certificate
Sheet
1
3
Warranty card
Sheet
1
4
Desiccant
Pack
1
5
Quick plug fittings
Pack
1
6
Maintenance CD*
Sheet
0
“*”- Not all products have this part.
A2. Transportation
Equipment should be handled with care in transportation to avoid severe impact. Equipment should be prevented
from being affected with damp and caught in the rain in transportation.
A3. Storage
Temperature for storage: -25℃~+50℃
Humidity for storage: relative humidity≤90%
Storage life: 12 months
Place for storage: ventilated indoor place without corrosive gas
