5
Winterizing
• Under no circumstances should the pump be left in frozen water.
• When the pump is out of use for an extended period, wash it and dry it thoroughly, then
store it indoors.
Note: When the pump is left installed in water it should be run at regular intervals (about once
per week).
Warranty
TidalWave Mag Drive Series Pumps carry a five-year limited warranty, excluding the
impeller and rotor, which have a one-year warranty. This limited warranty is extended solely to
the original purchaser commencing from the date of original purchase receipt and is void if
any of the following apply:
• The pump has been run while not fully submersed.
• The pump was not run on a dedicated circuit.
• The cord has been cut or altered.
• The pump has been misused or abused.
• Pump has been disassembled other than as described in this manual.
• Serial number tag has been removed.
Warranty Claims
• In case of warranty claims, pump should be returned to place of purchase accompanied
by original receipt.
Pre-filter
Volute
Intake
O-ring
Impeller
Assembly
Rotor
Chamber
Pump Body/Motor
Pump Base
(see larger image below)
Friction
Washer
Friction
Washer
Ceramic Shaft
Rubber
Bushing
Rubber
Bushing
Impeller/
Magnetic Rotor
