8 Technical data
8.1 Reference conditions and limitations
Reference conditions
Unit
Compressed air inlet pressure bar(e) 7
Compressed air inlet pressure psig 101.53
Compressed air inlet temperature (50 Hz units) °C 35
Compressed air inlet temperature (50 Hz units ) °F 95
Compressed air inlet temperature (60 Hz units) °C 38
Compressed air inlet temperature (60 Hz units) °F 100
Ambient temperature (50 Hz units) °C 25
Ambient temperature (50 Hz units) °F 77
Ambient temperature (60 Hz units) °C 38
Ambient temperature (60 Hz units) °F 100
Dewpoint (50 Hz units) °C 3
Dewpoint (50 Hz units) °F 37.4
Dewpoint (60 Hz units) °C 4
Dewpoint (60 Hz units) °F 39
Limits
Unit
Maximum compressed air inlet pressure bar(e) 13
Maximum compressed air inlet pressure psig 188.5
Minimum ambient temperature °C 3
Minimum ambient temperature °F 37
Maximum ambient temperature °C 46
Maximum ambient temperature °F 114
Maximum compressed air inlet temperature °C 60
Maximum compressed air inlet temperature °F 140
8.2 Air dryer data
FX 13 up to FX 16
Air dryer type Unit FX 13 FX 14 FX 15 FX 16 FX 13 FX 14 FX 15 FX 16
Frequency Hz 50 50 50 50 60 60 60 60
