8 Technical data
8.1 Readings on control panel
Pressure gauge GX 7 up to GX 11
Hourmeter
Dewpoint indicator
The readings mentioned below are valid under the reference conditions (see Reference
conditions and limitations).
Ref. Name
Gpa Air outlet pressure
Reading: Modulates between preset unloading/stopping pressure and loading pressure
Gdp Dew-point temperature
Reading: approx. 5˚C (41˚F) at 20˚C (68˚F) ambient temperature
Hm Hour meter
Reading: Total running time
Instruction book
64 2920 7054 00
