Atlas Copco LF 5 User Manual

2920 7090 00 25
Instruction book
9820 2239 43/05
81453D
Type Net mass (Kg) A B C D
LE/LT/LF 7 92 860 322 205 721
LE/LT/LF 10 104 932 322 205 721
LE 10 (60 Hz) 104 929 360 243 759
Compressor cooling
Air inlet
Cooling
Air outlet
Motor cooling
Air inlet
Compressor Air inlet
BM LE/LT/LF 7-10 YD
300
300
600
154 555
198
395
24
1
0
C C
D
4
0
For dismantling
Air filter
B
1
2
5
248 541
A
244
Compressed Air outlet
G1/2"
LF 7 up to LF 10, Base-mounted

Atlas Copco LF 5 Specifications

General

Brand	Atlas Copco
Model	LF 5
Category	Compressor
Language	English
