Atlas Copco OSC 355 User Manual

OSC 355
1 Condensate outlet (at rear side)
2 Service indicator (unit clogged)
3 Condensate inlet
4 Service indicator (oleophilic filter)
5 Mufflers
6 Oleophilic filters
7 Activated carbon filters
8 First tower
9 Second tower
10 Third tower
11 Test outlet
12 Diffuser
The condensate, containing fine oil droplets, enters the unit via mufflers (5) and is depressurised. The
condensate flows to the first tower and seeps through an oleophilic filter, which absorbs most of the oil.
Instruction book
AIF999999 9

Atlas Copco OSC 355 Specifications

General

Brand	Atlas Copco
Model	OSC 355
Category	Water Filtration Systems
Language	English
