Icon Description
Filter
Motor
Failure expansion module
Network problem
General alarm
The compressor module is running and can be stopped
The compressor module is stopped and is ready to start
The compressor module is awaiting the minimum stop time to expire
Menu icons
Icon Description
Inputs
Outputs
Alarms (Warnings, shutdowns)
Counters
or
Test
Settings
Instruction book
2920 7140 52 29
