Important remark:
You can select different timers on one day.(up to 8 actions). It is however not possible to
program 2 actions at the same time. The solution: leave at least 1 minute in between 2
actions.
Example: Start Compressor: 5.00 AM, Pressure Setpoint 2: 5.01 AM (or later).
Procedure
Starting from the Main screen,
•
Move the cursor to the action button Menu and press the Enter key. Use the Scroll buttons
to select the Timer icon.
Text on image
(1) Menu (2) Regulation
• Press the Enter key on the controller. Following screen appears:
Text on image
(1) Week Timer (4) Status
(2) Week Action Schemes (5) Week Timer Inactive
(3) Week Cycle (6) Remaining Running Time
The first item in this list is highlighted. Select the item to be adapted and press the Enter key
on the controller to modify.
Programming week schemes
•
Select Week action schemes and press Enter. A new window opens. The first item in the list
is highlighted in red. Press the Enter key on the controller to modify Week Action Scheme 1.
Instruction book
2920 7140 52 55
