Text on image
(1) Menu (2) Regulation
• Using the Scroll keys, move the cursor to the Setpoint icon (see above, section Menu icon)
•
Press the Enter key. Following screen appears:
Text on image
(1) Regulation (4) Pressure band 2 High
(2) Pressure band 1 High (5) Pressure band 2 Low
(3) Pressure band 1 Low (6) Modify
• The screen shows the actual stopping and starting pressure settings for both pressure
bands.
To modify the settings, move the cursor to the action button Modify and press the Enter key.
Following screen appears:
• The first line of the screen is highlighted. Use the Scroll keys to highlight the setting to be
modified and press the Enter key. Following screen appears:
Instruction book
50 2920 7140 52
